Hardware Specifications
asin number
B0C6EB5K89
model number
TN3402YAB-LZ541WS
Series
Vivobook S 14 Flip (2023)
processor
AMD Ryzen 5 7530U
CPU Core
6
CPU Threads
12
CPU Speed GHz
2.0 GHz to 4.5 GHz
CPU Cache MB
19
CPU Brand
AMD
CPU Series
Ryzen 5
CPU Model
7530U
CPU generation
7000 Series
ram
16 GB
ram type
DDR4
ram speed
3200 MHz
RAM Technology
8GB Onboard + 8GB SO-DIMM
RAM DDR Type
DDR4
RAM Slot Count
1
Max RAM Supported
24 GB
RAM Upgradeable
Yes
storage type
SSD
storage size
512 GB
SSD Slot Type
NVMe PCIe Gen3
Compatible SSD Type
M.2 2280
SSD Slot Count
1
Max Storage Supported Total GB
1024 GB
Storage Upgradeable
Yes (Replaceable)
graphics card
Integrated AMD Radeon Graphics
GPU DDR
Shared
GPU Size GB
Shared
has dedicated gpu
No
CPU Integrated GPU Model
AMD Radeon Graphics
operating system
Windows 11 Home
screen size
14 Inch
resolution
1920 x 1200 (WUXGA)
refresh rate
60 Hz
panel type
IPS-Level
aspect ratio
16:10
brightness
300 nits
colour gamut
45% NTSC
HDR support
No
Colour
Quiet Blue
Design
2-in-1 Convertible with 360-degree Hinge
Material
Metal (Top), Plastic (Bottom)
Touchscreen
Yes
webcam
1080p FHD camera with Privacy Shutter
Camera MP
2.0 MP
Camera Features
FHD Resolution, Privacy Shutter
ports
1x USB 2.0 Type-A, 1x USB 3.2 Gen 2 Type-A, 1x USB 3.2 Gen 2 Type-C (support display / power delivery), 1x HDMI 2.1 TMDS, 1x 3.5mm Combo Audio Jack
connectivity
Wi-Fi 6E (802.11ax) (Dual band) + Bluetooth 5.3
sensor
Fingerprint Sensor (Integrated with Power Button)
Display Features
Glossy display, TUV Rheinland-certified, 85% Screen-to-body ratio, Stylus Support
Special Features
360° Hinge, US MIL-STD 810H Military-grade durability, ASUS Antimicrobial Guard
Audio Features
Smart Amp Technology, harman/kardon (Mainstream), Built-in array microphone
Speaker
Built-in Speakers
Keyboard
Backlit Chiclet Keyboard
battery
3-Cell
battery life
6-8 Hours
battery Power
50 Whr
charger wattage
45W Adapter
cooling system type
ASUS IceCool Thermal Technology
User Serviceable Components
RAM (1 Slot), SSD
Repairability Score
6/10
weight
1.50 kg
dimensions
313.2 x 227.6 x 18.9 mm
launch year
2023
country of manufacture
China
included accessories
Power Adapter, User Manual (Stylus Pen may vary by region)
Warranty
1 Year Onsite Warranty
last edited at
2026-04-28 12:22:31
