Hardware Specifications
asin number
ASUS-VIVOBOOK-S14-S3402ZA-KM502WS
model number
S3402ZA-KM502WS
Series
Vivobook S 14 OLED
processor
Intel Core i5-12500H
CPU Core
12
CPU Threads
16
CPU Speed GHz
2.5 GHz to 4.5 GHz
CPU Cache MB
18
CPU Brand
Intel
CPU Series
Core i5
CPU Model
12500H
CPU generation
12th Gen
ram
16 GB
ram type
DDR4
ram speed
3200 MHz
RAM Technology
8GB Onboard + 8GB SO-DIMM
RAM DDR Type
DDR4
RAM Slot Count
1
Max RAM Supported
24 GB
RAM Upgradeable
Yes (via 1x SO-DIMM slot)
storage type
SSD
storage size
512 GB
SSD Slot Type
NVMe PCIe Gen4
Compatible SSD Type
M.2 2280
SSD Slot Count
1
Max Storage Supported Total GB
1024 GB
Storage Upgradeable
Yes (Replaceable)
graphics card
Integrated Intel Iris Xe Graphics
GPU DDR
Shared
GPU Size GB
Shared
has dedicated gpu
No
CPU Integrated GPU Model
Intel Iris Xe Graphics
operating system
Windows 11 Home
screen size
14 Inch
resolution
2880 x 1800 (2.8K OLED)
refresh rate
90 Hz
panel type
OLED
aspect ratio
16:10
brightness
600 nits HDR Peak Brightness
colour gamut
100% DCI-P3
HDR support
Yes (VESA CERTIFIED Display HDR True Black 600)
Colour
Neutral Grey / Indie Black / Brave Green
Design
Thin and Light with 180-degree Hinge
Material
Aluminum (Lid) / Plastic (Body)
Touchscreen
No
webcam
720p HD camera with Privacy Shutter
Camera MP
0.92 MP
Camera Features
Physical Privacy Shutter, 3D Noise Reduction
ports
2x Thunderbolt 4 (support display / power delivery), 1x USB 3.2 Gen 1 Type-A, 1x USB 2.0 Type-A, 1x HDMI 2.1, 1x 3.5mm Combo Audio Jack
connectivity
Wi-Fi 6E (802.11ax) + Bluetooth 5.3
sensor
Fingerprint Sensor (Integrated with Power Button)
Display Features
SGS Eye Care Display, PANTONE Validated, 1.07 Billion Colors
Special Features
Intel Evo Platform, MIL-STD 810H military-grade standard, ASUS IceCool Thermal Technology
Audio Features
Harman/Kardon (Mainstream), Smart Amp Technology
Speaker
Built-in Speakers
Keyboard
Backlit Chiclet Keyboard
battery
3-Cell
battery life
Up to 8 Hours
battery Power
70 Whr
charger wattage
90W AC Adapter
cooling system type
ASUS IceCool (Dual Heat Pipes/97-blade Fan)
User Serviceable Components
RAM (1 Slot), SSD
Repairability Score
6/10
weight
1.50 kg
dimensions
316.4 x 224.5 x 18.9 mm
launch year
2022
country of manufacture
China
included accessories
Power Adapter, User Manual
Warranty
1 Year Onsite Warranty
