Hardware Specifications
asin number
ASUS-VIVO-S15-S5506MA-MA952WS
model number
S5506MA-MA952WS
Series
Vivobook S 15 OLED (2024)
processor
Intel Core Ultra 9 185H
CPU Core
16
CPU Threads
22
CPU Speed GHz
2.3 GHz to 5.1 GHz
CPU Cache MB
24
CPU Brand
Intel
CPU Series
Core Ultra 9
CPU Model
185H
CPU generation
Series 1
ram
16 GB
ram type
LPDDR5X
ram speed
7467 MHz
RAM Technology
LPDDR5X Onboard
RAM DDR Type
LPDDR5X
Max RAM Supported
16 GB
RAM Upgradeable
No
storage type
SSD
storage size
1 TB
SSD Slot Type
NVMe PCIe Gen4
Compatible SSD Type
M.2 2280
SSD Slot Count
1
Max Storage Supported Total GB
1024 GB
Storage Upgradeable
Yes (Replaceable)
graphics card
Integrated Intel Arc Graphics
GPU DDR
Shared
GPU Size GB
Shared
has dedicated gpu
No
CPU Integrated GPU Model
Intel Arc Graphics
operating system
Windows 11 Home
screen size
15.6 Inch
resolution
2880 x 1620 (3K)
refresh rate
120 Hz
panel type
OLED
aspect ratio
16:9
brightness
400 nits (600 nits Peak)
colour gamut
100% DCI-P3
HDR support
Yes (VESA DisplayHDR True Black 600)
Colour
Neutral Black
Design
Ultra-slim Full Metal Body (1.39 cm)
Material
Aluminum (Full Body)
Touchscreen
No
webcam
FHD camera with IR function and Privacy Shutter
Camera MP
2.0 MP
Camera Features
Windows Hello support, Privacy Shutter
ports
2x Thunderbolt 4 (DP / Power Delivery), 2x USB 3.2 Gen 1 Type-A, 1x HDMI 2.1 TMDS, 1x Micro SD card reader, 1x Audio Combo Jack
connectivity
Wi-Fi 6E (802.11ax) + Bluetooth 5.3
sensor
N/A
Display Features
Glossy, 1,000,000:1 Contrast Ratio, 0.2ms Response Time, TUV Rheinland certified
Special Features
Intel Evo Certified, Dedicated Copilot Key, ASUS IceCool Thermal Technology (Up to 50W TDP)
Audio Features
Harman/Kardon (Mainstream), Dolby Atmos, Smart Amp Technology
Speaker
Built-in Speakers
Keyboard
Single-Zone RGB Backlit Chiclet Keyboard
battery
4-Cell
battery life
Up to 16 Hours
battery Power
75 Whr
charger wattage
90W AC Adapter (Type-C)
cooling system type
ASUS IceCool Dual Fans (97 Blades)
User Serviceable Components
SSD Only
Repairability Score
6/10
weight
1.50 kg
dimensions
353.6 x 246.9 x 13.9 ~ 15.9 mm
launch year
2024
country of manufacture
China
included accessories
Power Adapter, User Manual
Warranty
1 Year Onsite Warranty
